Nauticam Wet Wide Lens for compact cameras (WWL-C) [83203]

With the original Wet Wide Lens, the WWL-1, Nauticam used computer aided lens design software to create an underwater-specific corrective lens that allowed for an unprecedented 130º field-of-view with full zoom-through optics and extreme close focus capabilities.  The WWL-1 wasn't just for higher end cameras that already benefitted from interchangeable lenses to attain better image quality, the WWL-1 was designed to work with a variety of cameras that featured a 28mm equivalent lens including compacts and micro-four thirds.

Delivering a stunningly sharp 130º field-of-view with 24mm equivalent lenses, the WWL-C also features zoom-through capable optics.** The WWL-C features a pre-installed metal buoyancy collar and a non-removable metal dome shade.

The WWL-C will also feature an updated quick-release Bayonet Mount.  Lenses that feature the new Bayonet Mount II will not be compatible with previous Bayonet Mount adapters but all Bayonet Mount lenses will be able to be used with the new Bayonet Mount II Bayonet Mount Adapters without modification.

In the sidebar you will find a list of anticipated housing compatibility along with the supported focal-length range as well as the necessary port configuration for the Bayonet Mount II standard.

**= not all camera configurations support full zoom-through

Specifications:

Dimensions: Ø146mm x 79mm
Weight in Air: 1.05kg
Weight in Water: 0.17kg
Lens Construction: 4 elements
Lens Coatings: Anti-reflective on both sides
Dome Coating: Multi-layer Broad-band Antireflective Coating
Focal Range: Front Element to Infinity
Maximum Field of View (underwater): 130º for 24mm equivalent lens
Mounting System: Bayonet Mount
Depth Rating: 100m

Expected Camera Compatibility Table
